Spinners, prop adapters/balancers
The following items are available from D&L Designs

Ultimate Profile
Precision Turned Aluminum Barstock
Spinners


Manufactured by
Paragon Aeronautics
Tucson, AZ
(520)-571-8880
www.paragonaero.com
Specifications:
10-32 center bolt,
12mm center hole,
10mm & 3/8" reducer bushings supplied,
2-blade Menz prop cutouts standard
spinners

Standard Backplate
Diameter Length Weight (oz) Part No. Price
3.0 3.4 2.9 U3001 46.50
3.5 4.0 4.1 U3501 62.50
4.0 4.6 5.5 U4001 82.00
4.5 5.2 7.4 U4501 106.50
5.0 5.8 9.4 U5001 133.50
5.5 6.4 11.8 U5501 167.00
6.0 7.0 15.3 U6001 205.50
3W Drill Pattern
Diameter Length Weight (oz) Part No. Price
3.0 3.4 2.7 U3002 52.00
3.5 4.0 3.9 U3502 68.00
4.0 4.6 5.3 U4002 87.50
4.5 5.2 7.2 U4502 112.00
5.0 5.8 9.2 U5002 139.00
5.5 6.4 11.6 U5502 172.50
6.0 7.0 15.1 U6002 211.00
Light Backplate / 3W Drill Pattern
Diameter Length Weight (oz) Part No. Price
3.0 3.4 2.5 U3003 57.00
3.5 4.0 3.4 U3503 75.00
4.0 4.6 4.4 U4003 95.00
4.5 5.2 5.9 U4503 121.00
5.0 5.8 7.7 U5003 149.00
5.5 6.4 9.7 U5503 186.00
6.0 7.0 12.7 U6003 227.00
Standard
Precision Turned Aluminum Barstock
Spinners
Solid Backplate
Diameter Length Weight (oz) Part No. Price
2.75 2.75 2.4 S2701 38.50
3.0 3.0 2.8 S3001 44.00
3.25 3.25 3.4 S3201 53.00
3.5 3.5 4.0 S3501 59.00
3.75 3.75 4.7 S3701 69.50
4.0 4.0 5.4 S4001 77.50
3W Drill Pattern
Diameter Length Weight (oz) Part No. Price
2.75 2.75 2.3 S2702 44.00
3.0 3.0 2.7 S3002 49.50
3.25 3.25 3.3 S3202 58.50
3.5 3.5 3.9 S3502 64.50
3.75 3.75 4.6 S3702 75.00
4.0 4.0 5.3 S4002 83.00
Prop Shaft Adapters and Extensions
Adapters (25mm length)
Thread Part No. Price
1/4-28* A0250 6.45
M7x1.00* A0276 6.45
5/16-24* A0312 6.45
M8x1.00* A0315 6.45
M8x1.25* A0316 6.45
3/8-24 A0375 6.45
M10x1.00 A0394 6.45
M10x1.25 A0395 6.45
Heat treated stainless steel; 10-32 internal spinner bolt thread
*includes 3/8 O.D. Ultem bushing
Extensions
Thread Part No. Price
3/8" hex base, 10-32 thread stud E0190 6.45
3/8" hex base, M6x1 thread stud E0236 6.45
8mm diameter, M4x.7 thread stud E0315 9.75
10mm diameter, M5x.8 thread stud E0394 10.50
Heat treated stainless steel; 10-32 internal spinner bolt thread
Prop Shaft Adapter Bushings (3/8 OD)
Thread Part No. Price
1/4 (7MM),
5/16 (8MM)
B375U 2.95
3/8" O.D. Utlem plastic, 380 max temp. rating;
includes 1 each 1/4", 7mm, 5/16" and 8 mm I.D.
Metal Air Line and Fuel Line Fittings
Air Line Fittings
Size / Type Part No. Price
1/16 Straight F062S 1.95
1/16 Tee F062T 3.95
Fuel Line Fittings
Size / Type Part No. Price
1/8 Straight F125S 1.95
1/8 Tee F125T 3.95
Fingertip Prop Balancers
Stainless Steel
Scale Part No. Price
Inch PB375 4.95
Metric PB394 5.95
Fuel Dots for Glow or Gas Engines
Price
Combo
includes filler, tee, & vent
For Gas Engines 11.95
Combo
includes filler & tee
For Glow Engines
(w/pressurized tank)
16.95
Filler only 5.95
Tee only 5.45
Vent only 3.95

Please add p&h to each order as follows:

Spinners: add $5.00
Propshaft Adapters and Extensions, Air and Fuel Line Fittings,
or Prop Balancers: add $2.00
Fuel Dots, Filler, Tee, & Vent: add $2.00


credit cards accepted
Send check or money order to

D&L Designs
1145 E. Kleindale Rd.
Tucson, AZ 85719
Ph: (520)-887-0771
