Ultimate Profile
Precision Turned Aluminum Barstock
Spinners
Manufactured by
Paragon Aeronautics
Tucson, AZ
(520)-571-8880
www.paragonaero.com
|
Specifications: 10-32 center bolt, 12mm center hole, 10mm & 3/8" reducer bushings supplied, 2-blade Menz prop cutouts standard |
|
| Standard Backplate | ||||
| Diameter | Length | Weight (oz) | Part No. | Price |
| 3.0 | 3.4 | 2.9 | U3001 | 46.50 |
| 3.5 | 4.0 | 4.1 | U3501 | 62.50 |
| 4.0 | 4.6 | 5.5 | U4001 | 82.00 |
| 4.5 | 5.2 | 7.4 | U4501 | 106.50 |
| 5.0 | 5.8 | 9.4 | U5001 | 133.50 |
| 5.5 | 6.4 | 11.8 | U5501 | 167.00 |
| 6.0 | 7.0 | 15.3 | U6001 | 205.50 |
| 3W Drill Pattern | ||||
| Diameter | Length | Weight (oz) | Part No. | Price |
| 3.0 | 3.4 | 2.7 | U3002 | 52.00 |
| 3.5 | 4.0 | 3.9 | U3502 | 68.00 |
| 4.0 | 4.6 | 5.3 | U4002 | 87.50 |
| 4.5 | 5.2 | 7.2 | U4502 | 112.00 |
| 5.0 | 5.8 | 9.2 | U5002 | 139.00 |
| 5.5 | 6.4 | 11.6 | U5502 | 172.50 |
| 6.0 | 7.0 | 15.1 | U6002 | 211.00 |
| Light Backplate / 3W Drill Pattern | ||||
| Diameter | Length | Weight (oz) | Part No. | Price |
| 3.0 | 3.4 | 2.5 | U3003 | 57.00 |
| 3.5 | 4.0 | 3.4 | U3503 | 75.00 |
| 4.0 | 4.6 | 4.4 | U4003 | 95.00 |
| 4.5 | 5.2 | 5.9 | U4503 | 121.00 |
| 5.0 | 5.8 | 7.7 | U5003 | 149.00 |
| 5.5 | 6.4 | 9.7 | U5503 | 186.00 |
| 6.0 | 7.0 | 12.7 | U6003 | 227.00 |
|
||||
|
Standard Precision Turned Aluminum Barstock Spinners |
||||
| Solid Backplate | ||||
| Diameter | Length | Weight (oz) | Part No. | Price |
| 2.75 | 2.75 | 2.4 | S2701 | 38.50 |
| 3.0 | 3.0 | 2.8 | S3001 | 44.00 |
| 3.25 | 3.25 | 3.4 | S3201 | 53.00 |
| 3.5 | 3.5 | 4.0 | S3501 | 59.00 |
| 3.75 | 3.75 | 4.7 | S3701 | 69.50 |
| 4.0 | 4.0 | 5.4 | S4001 | 77.50 |
| 3W Drill Pattern | ||||
| Diameter | Length | Weight (oz) | Part No. | Price |
| 2.75 | 2.75 | 2.3 | S2702 | 44.00 |
| 3.0 | 3.0 | 2.7 | S3002 | 49.50 |
| 3.25 | 3.25 | 3.3 | S3202 | 58.50 |
| 3.5 | 3.5 | 3.9 | S3502 | 64.50 |
| 3.75 | 3.75 | 4.6 | S3702 | 75.00 |
| 4.0 | 4.0 | 5.3 | S4002 | 83.00 |
|
|
||||
| Prop Shaft Adapters and Extensions | ||||
| Adapters (25mm length) | ||||
| Thread | Part No. | Price | ||
| 1/4-28* | A0250 | 6.45 | ||
| M7x1.00* | A0276 | 6.45 | ||
| 5/16-24* | A0312 | 6.45 | ||
| M8x1.00* | A0315 | 6.45 | ||
| M8x1.25* | A0316 | 6.45 | ||
| 3/8-24 | A0375 | 6.45 | ||
| M10x1.00 | A0394 | 6.45 | ||
| M10x1.25 | A0395 | 6.45 | ||
|
Heat treated stainless steel; 10-32 internal spinner bolt thread *includes 3/8 O.D. Ultem bushing |
||||
| Extensions | ||||
| Thread | Part No. | Price | ||
| 3/8" hex base, 10-32 thread stud | E0190 | 6.45 | ||
| 3/8" hex base, M6x1 thread stud | E0236 | 6.45 | ||
| 8mm diameter, M4x.7 thread stud | E0315 | 9.75 | ||
| 10mm diameter, M5x.8 thread stud | E0394 | 10.50 | ||
| Heat treated stainless steel; 10-32 internal spinner bolt thread | ||||
| Prop Shaft Adapter Bushings (3/8 OD) | ||||
| Thread | Part No. | Price | ||
|
1/4 (7MM), 5/16 (8MM) |
B375U | 2.95 | ||
|
3/8" O.D. Utlem plastic, 380° max temp. rating; includes 1 each 1/4", 7mm, 5/16" and 8 mm I.D. |
||||
|
|
||||
| Metal Air Line and Fuel Line Fittings | ||||
| Air Line Fittings | ||||
| Size / Type | Part No. | Price | ||
| 1/16 Straight | F062S | 1.95 | ||
| 1/16 Tee | F062T | 3.95 | ||
| Fuel Line Fittings | ||||
| Size / Type | Part No. | Price | ||
| 1/8 Straight | F125S | 1.95 | ||
| 1/8 Tee | F125T | 3.95 | ||
|
|
||||
| Fingertip Prop Balancers | ||||
| Stainless Steel | ||||
| Scale | Part No. | Price | ||
| Inch | PB375 | 4.95 | ||
| Metric | PB394 | 5.95 | ||
|
|
||||
| Fuel Dots for Glow or Gas Engines | ||||
| Price | ||||
|
Combo includes filler, tee, & vent
|
For Gas Engines | 11.95 | ||
|
Combo includes filler & tee
|
For Glow Engines (w/pressurized tank) |
16.95 | ||
| Filler only | 5.95 | |||
| Tee only | 5.45 | |||
| Vent only | 3.95 | |||
|
Please add p&h to each order as follows: Spinners: add $5.00 Propshaft Adapters and Extensions, Air and Fuel Line Fittings, or Prop Balancers: add $2.00 Fuel Dots, Filler, Tee, & Vent: add $2.00
Send check or money order to D&L Designs 1145 E. Kleindale Rd. Tucson, AZ 85719 Ph: (520)-887-0771 email: dldesigns@mindspring.com
|
